But this also means, for targets closer than infinity, sighting towards the edge of the optical window can make the reticle move in relation to the target since the observer is sighting down a parallel light bundle at the edge.
The collimated reticle image can also be seen at any eye position in the cylindrical volume of collimated light created by the sight behind the optical window. Since the optical collimator produces a reticle image made up of collimated light, light that is nearly parallel, the light making up that image is theoretically perfectly parallel with the axis of the device or gun barrel it is aligned with, i.e. The image is reflected off some form of angled beam splitter or the partially silvered collimating curved mirror itself so that the observer (looking through the beam splitter or mirror) will see the image at the focus of the collimating optics superimposed in the sight's field of view in focus at ranges up to infinity. Reflector sights work by using a lens or an image-forming curved mirror with a luminous or reflective overlay image or reticle at its focus, creating an optical collimator that produces a virtual image of that reticle. The bottom two use half silvered curved mirrors (CM) as the collimating optics The top uses a collimating lens (CL) and a beam splitter (B) to create a virtual image at infinity (V) of a reticle (R). Other applications of reflector sights include sights on surveying equipment, optical telescope pointing aids, and camera viewfinders.ĭesign Diagram of three types of reflector sights. This sight uses a red light-emitting diode (LED) as its illumination source, making a durable, dependable sight with an extremely long illumination run time. There was some limited use of the sight on small arms after World War II, but the sight came into widespread use during the late 1970s with the invention of the red dot sight. They have been used in other types of (usually large) weapons as well, such as anti-aircraft gun sights, anti-tank gun sights, and any other role where the operator had to engage fast moving targets over a wide field of view, and the sight itself could be supplied with sufficient electrical power to function. They were used on fighter aircraft, in a limited capacity in World War I, widely used in World War II, and still used as the base component in many types of modern head-up displays. Since their invention in 1900, reflector sights have come to be used as gun sights on various weapons. Since the reticle is at infinity it stays in alignment with the device to which the sight is attached regardless of the viewer's eye position, removing most of the parallax and other sighting errors found in simple sighting devices.
Reflector sights employ some sort of "reflector" to allow the viewer to see the infinity image and the field of view at the same time, either by bouncing the image created by lens off a slanted glass plate, or by using a mostly clear curved glass reflector that images the reticle while the viewer looks through the reflector. These sights work on the simple optical principle that anything at the focus of a lens or curved mirror (such as an illuminated reticle) will appear to be sitting in front of the viewer at infinity. The dot remains on the target even though the viewer's head is moved side to sideĪ reflector sight or reflex sight is an optical sight that allows the user to look through a partially reflecting glass element and see an illuminated projection of an aiming point or some other image superimposed on the field of view. The reticle image in this sight is produced by an optical collimator bounced off a beam splitter.
Curved photo reflector free#
Optical device for aiming A view through the Mark III Free Gun Reflector Sight, first produced in 1943, used on British army guns, naval guns, and as a pilot sight and a defensive gun sight on aircraft.
